รายละเอียด
| CL Series Specifications | ||||||||
|
Level Start-Type Model |
CL-4000 | CL-6000 | CL-6500 | CL-7000 | ||||
|
Push-to-Start-Type Model |
CL-4000PS | CL-6000PS | CL-6500PS |
CL-7000PS |
||||
|
Output |
N – m | 0.1 – 0.55 | 0.2 – 1 | 0.3 – 1.6 |
0.3 – 2.5 |
|||
|
Torque Range |
Lbf – in | 0.9 – 4.8 | 1.7 – 8.8 | 2.6 – 1.4 | 2.6 – 22 | |||
| (kgf – cm) | (1- 5.5) | (2 – 10) | (3-16) |
(3 – 25) |
||||
|
Torque Switching |
Stepless adjustment | Stepless adjustment | Stepless adjustment |
Stepless adjustment |
||||
|
Unloaded Rotation |
HI | 1,000 | 800 | 900 | 750 | |||
|
Speed (r.p.m)±10% |
LOW | 690 | 500 | 600 |
500 |
|||
|
Screw Size(mm) |
Machine Screw | 1.4 – 2.6 | 2.0 – 3.0 | 2.0 – 4.0 | 2.0 – 5.0 | |||
| Tapping Screw | 1.4 – 2.3 | 2.0 – 2.6 | 2.0 – 3.0 |
2.0 – 4.0 |
||||
|
Bit Drive |
HlOS Shank | H4 | H5 | H5 |
H5 |
|||
|
HEX Shank |
1/4HEX or 5HEX | 1/4HEX or 5HEX | 1/4HEX or 5HEX |
1/4HEX or 5HEX |
||||
